Operating Guide | VLT® AQUA Drive FC 202
1
2
3
4
L1
L2
L3
PE
5
1 Programmable logic controller (PLC)
3 Control cables
5 Mains supply
7 Star washers
9 Motor cable (shielded)
44 | Danfoss A/S © 2018.10
90
4
4
2 Minimum 16 mm
2
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables
6 Bare (unpainted) surface
8 Brake cable (shielded)
10 Mains cable (unshielded)
Electrical Installation
u
v
w
PE
(6 AWG) equalizing cable
AQ262141056213en-000101 / 130R0882
