Operating Guide | VLT® AQUA Drive FC 202
R
S
T
L1R
L2S
L3T
Illustration 40:
Connecting Motor and Mains Cables (Example Shows a PHF Cabinet + Input Power Options Cabinet + E6h Drive Cabinet + Sine-
wave Cabinets)
5.7 Control Compartment Wiring
5.7.1 Safety Precautions
HIGH VOLTAGE
The mains disconnect switch does not disconnect the external voltage supply. Failure to disconnect the external voltage supply
before touching any components in the control compartment can result in death or serious injury.
Only qualified personnel must install, start up, and maintain the drive.
-
Disconnect the external voltage supply.
-
66 | Danfoss A/S © 2018.10
R S T
R S T
W A R N I N G
U V W
Electrical Installation
AQ262141056213en-000101 / 130R0882
