Operating Guide | VLT® AQUA Drive FC 202
FC 202
Typical shaft output at 575 V [hp]
Typical shaft output at 690 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 550 V) [A]
Intermittent (60 s overload) (at 550 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690 V) [A]
Continuous kVA (at 550 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Maximum input current
Continuous (at 550 V) [A]
Continuous (at 575/690 V) [A]
Maximum number and size of cables per phase
2
- Mains [mm (AWG)]
- Mains with disconnect [mm
- Mains with fusible disconnect [mm
- Mains with contactor [mm
2
- Motor [mm (AWG)]
Drive module power loss at 600 V [W]
Drive module power loss at 690 V [W]
Drive efficiency (2)
Output frequency [Hz] (4)
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
PHF overtemperature trip [°C (°F)]
dU/dt filter overtemperature trip [°C (°F)]
Sine-wave filter overtemperature trip [°C (°F)]
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These values are based on a typical motor
efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimensioning of drive cooling. If the switching frequency is higher than the default
setting, the power losses can increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/
knowledge-center/energy-efficiency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficiency class, see the Ambient Conditions
section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
Danfoss A/S © 2018.10
2
(AWG)]
2
(AWG)]
2
(AWG)]
(1) (2) (3)
(1) (2) (3)
N630 N710
600 650 650
560 630 630
E5h E6h
596 630 659
894 693 989
570 630 630
855 693 945
568 600 628
568 627 627
681 753 753
574 607 635
549 607 607
4x120 (4x250 mcm) 4x185 (4x350 mcm)
4x120 (4x250) 4x185 (4x350 mcm)
4x120 (4x250) 4x185 (4x350 mcm)
4x120 (4x250) 4x185 (4x350 mcm)
4x120 (4x250) 4x185 (4x350 mcm)
8069 9208 8543
7848 8921 8363
0.98 0.98
0–590 0–590
110 (230) 110 (230)
80 (176) 80 (176)
150 (302) 150 (302)
150 (302) 150 (302)
150 (302) 150 (302)
AQ262141056213en-000101 / 130R0882 | 169
Specifications
N800
750 750 950
710 710 800
E6h
763 763 889
839 1145 978
730 730 850
803 1095 935
727 727 847
727 727 847
872 872 1016
735 735 857
704 704 819
4x185 (4x350 mcm)
4x185 (4x350 mcm)
4x185 (4x350 mcm)
4x185 (4x350 mcm)
4x185 (4x350 mcm)
10346 10319 12723
10066 10060 12321
0.98
0–590
110 (230)
80 (176)
150 (302)
150 (302)
150 (302)
