11.6.3 Non-fusible Disconnect Losses

Table 126: Power Losses for Non-fusible Disconnect Option, 380–500 V (Losses Shown in Watts)
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N450
N500
Table 127: Power Losses for Non-fusible Disconnect Option, 525–690 V (Losses Shown in Watts)
Model
–
N90K
N110
N132
N160
N200
N250
N315
N355
N400
N500
N560
200 | Danfoss A/S © 2018.10
525–550 V
173 154
208 155
282 208
380–440 V
NO HO
8 6
13 8
19 13
29 19
44 29
65 44
25 21
32 25
36 27
43 36
55 43
525–550 V
NO HO
4 2
5 4
8 5
12 8
17 12
24 17
33 24
42 29
52 35
20 16
23 20
551–690 V
173 141
190 142
258 190
441–500 V
NO HO
7 5
11 7
17 11
25 17
37 25
54 37
20 17
26 20
30 26
34 30
44 34
551–690 V
NO HO
3 2
5 3
7 5
11 7
16 11
22 16
30 22
38 27
47 32
19 14
23 19
