Operating Guide | VLT® AQUA Drive FC 202
10.9.5 E6h Enclosed Drive Dimensions
55
(2.2)
1
2000
(78.7)
100
6
(3.9)
800 (31.5)
1 Passive harmonic filter/line reactor cabinet
3 E6h drive cabinet
5 dU/dt cabinet
Illustration 75:
Dimensions for E6h Enclosure with Standard Pedestal
Danfoss A/S © 2018.10
2
600 (23.6)
600 (23.6)
2 Options cabinet
4 Sine-wave cabinet
6 Standard pedestal
3
5
400
(15.8)
AQ262141056213en-000101 / 130R0882 | 189
Specifications
4
1200 (82.7)
