Operating Guide | VLT® AQUA Drive FC 202
1
2
5
1 Input filter cabinet (passive harmonic filter or line reactor)
3 Drive cabinet
5 Control compartment
Illustration 3:
Possible Configurations for an E5h or E6h Enclosed Drive
Danfoss A/S © 2018.10
3
3
4
6
2 Input power options cabinet
4 Sine-wave filter cabinet
6 dU/dt filter cabinet
AQ262141056213en-000101 / 130R0882 | 15
Product Overview
