Operating Guide | VLT® AQUA Drive FC 202
Example:
1
2
3
4
5
6
1 Cabinet screen (lower)
3 Terminal cover
5 Ground terminals on drive module
Illustration 52:
Connection Points for Drive Module to Motor
86 | Danfoss A/S © 2018.10
2 DC terminals
4 Motor terminals
6 Grounding bar
Electrical Installation
AQ262141056213en-000101 / 130R0882
