Operating Guide | VLT® AQUA Drive FC 202
Table 57: Wiring Configuration for Analog Voltage Feedback Transducer (4-wire)
+24 V XD2.10
+24 V XD2.11
D IN
XD2.12
D IN XD2.13
COM XD2.18
D IN XD2.14
XD2.15
D IN
D IN XD2.16
XD2.17
D IN
D IN XD2.19
+10 V XD2.6
+
A IN XD2.7
A IN XD2.8
COM XD2.9
A OUT XD2.5
-
COM XD2.4
0-10 V
U - I
A54

8.1.5 Wiring Configuration: Run/Stop

Table 58: Wiring Configuration for Run/Stop Command with External Interlock
+24 V XD2.10
+24 V XD2.11
D IN XD2.12
D IN XD2.13
XD2.18
COM
D IN XD2.14
XD2.15
D IN
D IN XD2.16
D IN XD2.17
D IN XD2.19
Danfoss A/S © 2018.10
Parameters
Function
Parameter 6-20 Terminal 54 Low Voltage
Parameter 6-21 Terminal 54 High Voltage
Parameter 6-24 Terminal 54 Low Ref./Feedb. value
Parameter 6-25 Terminal 54 High Ref./Feedb. Value
*=Default value
Notes/comments:
D IN 37 is an option.
Terminal 54 in the parameter title corresponds to terminal XD2.8 in the control compartment.
Parameter
Function
Parameter 5-10 Terminal 18 Digital Input
Parameter 5-12 Terminal 27 Digital Input
*=Default value
Notes/comments:
D IN 37 is an option.
Terminal 18 in the parameter title corresponds to terminal XD2.12 in the control compartment.
Terminal 27 in the parameter title corresponds to terminal XD2.14 in the control compartment.
Wiring Configuration Examples
Setting
0.07 V*
10 V*
0*
50*
Setting
[8] Start*
[7] External interlock
AQ262141056213en-000101 / 130R0882 | 115
