Operating Guide | VLT® AQUA Drive FC 202
-QB2 Mains fused disconnect
-MA7 dU/dt and sine-wave filter fans
-RF2 Sine-wave filter inductor
-RF1 dU/dt filter inductor
-RF3 Common-mode filter
-TA1 Drive module
Illustration 77:
Electrical Power Flow for D9h/D10h Enclosure
196 | Danfoss A/S © 2018.10
-QB8 Mains disconnect
-MA8 PHF fans
-CA4 Sine-wave filter capacitor
-CA3 dU/dt filter capacitor
-MA1 Motor (customer side)
LCP Local control panel
Appendix
AQ262141056213en-000101 / 130R0882
