Operating Guide | VLT® AQUA Drive FC 202
MCCB
With the recommended MCCBs, the SCCR for the drive system can be declared as shown below.

10.8.2 Panel Fuses

Panel fuses are an option for upstream protection, and can be ordered as either a UL class fuse for UL variant or a gG fuse for IEC
variant.
Table 90: Panel Fuses for N110K–N315 Models, 380–480 V
N110
IEC (Type gG)
250 A/500 V
Mersen P/N NH1GG50V250
UL (Class J/L/T) 300 A/600 V
Mersen P/N A4J300
Table 91: Panel Fuses for N355–N560 Models, 380–480 V
N355
IEC (Type gG) 800 A/500 V
Mersen P/N NH4GG50V800
UL (Class J/L/T) 800 A/600 V
Mersen P/N A4BY800
Table 92: Panel Fuses for N110–N315 Models, 525–690 V
N110
IEC (Type gG) 250 A/690 V
Mersen P/N NH2GG69V250
UL (Class J/L/T) 175 A/600 V
Mersen P/N A4J175
Table 93: Panel Fuses for N400–N630 Models, 525–690 V
N400
IEC (Type gG) 500 A/690 V
Mersen P/N NH3GG69V500
UL (Class J/L/T)
600 A/600 V
Mersen P/N A4J600
180 | Danfoss A/S © 2018.10
N132 N160
315 A/500 V 355 A/500 V
NH2GG50V315 NH2GG50V355
350 A/600 V 400 A/600 V
A4J350 A4J400
N400
1000 A/500 V
NH4GG50V1000
1000 A/600 V
A4BY1000
N132 N160
250 A/690 V 250 A/690 V
NH2GG69V250 NH2GG69V250
200 A/600 V 250 A/600 V
A4J200 A4J250
N450
500 A/500 V
NH3GG69V500
600 A/600 V
A4J600
N200
425 A/500 V
NH3GG50V425
500 A/600 V
A4J500
N450 N500
1000 A/500 V 1000 A/500 V
NH4GG50V1000 NH4GG50V1000
1000 A/600 V 1100 A/600 V
A4BY1000 A4BY1100
N200
315 A/690 V
NH2GG69V315
350 A/600 V
A4J350
N500 N560
630 A/500 V 800 A/500 V
NH4GG69V630 NH4GG69V800
650 A/600 V 750 A/600 V
A4BY650 A4BY750
Specifications
N250 N315
630 A/500 V 630 A/500 V
NH3AGG50V630 NH3AGG50V630
600 A/600 V 750 A/600 V
A4J600 AABY750
N560
1250 A/500 V
NH4GG50V1250
1200 A/600 V
A4BY1200
N250 N315
355 A/690 V 425 A/690 V
NH3GG69V355 NH3GG69V425
400 A/600 V 500 A/600 V
A4J400 A4J500
N630
800 A/500 V
NH4GG69V800
800 A/600 V
A4BY800
