Operating Guide | VLT® AQUA Drive FC 202
Callout Key Function
E4 Auto On Puts the system in remote operational mode so it can respond to an external start command by control
terminals or serial communication.

3.6.4 LCP Menu

Quick Menus
The Quick Menus mode provides a list of menus used to configure and operate the drive. Select the Quick Menus mode by pressing the
[Quick Menus] key. The resulting readout appears on the LCP display.
0.0%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Illustration 10: Quick Menu View
Q1 My Personal Menu
The Personal Menu is used to determine what is shown in the display area. Refer to
show up to 50 pre-programmed parameters. These 50 parameters are manually entered using parameter 0-25 My Personal Menu.
Q2 Quick Setup
The parameters found in the Q2 Quick Setup contain basic system and motor data that are always necessary for configuring the drive.
See 7.2.4 Entering System Information
Q3 Function Setups
The parameters found in the Q3 Function Setups contain data for fan, compressor, and pump functions. This menu also includes
parameters for LCP display, digital preset speeds, scaling of analog references, closed-loop single zone, and multizone applications.
Q4 Smart Setup
Q4 Smart Setup guides the user through typical parameter settings used to configure 1 of the following 3 applications:
• Mechanical brake.
• Conveyor.
• Pump/fan.
The [Info] key can be used to see help information for various selections, settings, and messages.
Q5 Changes Made
Select Q5 Changes Made for information about:
Danfoss A/S © 2018.10
0.00
1(1)
for the set-up procedures.
3.6.3 Local Control Panel (LCP). This menu can also
AQ262141056213en-000101 / 130R0882 | 29
