Operating Guide | VLT® AQUA Drive FC 202
Noise level
1
The current ratings for the E5h and E6h enclosures are achieved by filter paralleling.
Table 88: dU/dt Filter Configurations for D9h–D10h and E5h–E6h Enclosures, 380–480 V
Enclosure
D9h
D9h
D9h
D10h
D10h
D10h
E5h
E5h
E5h
E6h
E6h
Table 89: dU/dt Filter Configurations for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure
D9h
D9h
D9h
D10h
D10h
D10h
D10h
E5h
E5h
E5h
E5h
E6h
E6h

10.7.4 Sine-wave Filter Specifications

Voltage rating
Nominal current @ 50 Hz
178 | Danfoss A/S © 2018.10
Model Current rating [A]
N110 261
N132 261
N160 418
N200 418
N250 590
N315 590
N355 418
N400 418
N450 418
N500 590
N560 590
Model Current rating [A]
N110 144
N132 261
N160 261
N200 418
N250 418
N315 418
N355 418
N400 590
N500 418
N560 418
N630 418
N710 590
N800 590
Filters required
1
1
1
1
1
1
2
2
2
2
2
Filters required
1
1
1
1
1
1
1
1
2
2
2
2
2
212 A and 315 A for 380–480 V, 137 A and 222 A for 525–690 V
Specifications
< drive module
3x380–480 V and 525–690 V AC
AQ262141056213en-000101 / 130R0882
(1)
