Operating Guide | VLT® AQUA Drive FC 202
XD2 ter- Parameter
minal
19 –
Table 27: Analog Input/Output Terminal Descriptions
XD2 termi- Parameter
nal
4 –
5 Parameter 6-50 Terminal 42 Out-
put
6 –
7 Parameter group 6-1* Analog In-
put 1
8 Parameter group 6-2* Analog In-
put 2
9 –

5.7.4 Relay Terminals

Table 28: Relay Terminal Descriptions
XD2 terminal Parameter
21, 22, 23 Parameter 5-40 Function Relay [0]
24, 25, 26 Parameter 5-40 Function Relay [1]

5.7.5 Option Card Terminals

The option cards extend the functionality of drives and provide a high variety of interfaces to automation systems. When the option
cards are specified in the type code, they are mounted in slots A, B, C, and D of the control card within the drive module. The option
card wiring is routed to a terminal block within the control compartment. For more details, refer to the installation/operating guide for
the respective option card.
OPTION CARD INSTALLATION
If the option card is ordered along with the drive using the type code, the factory installs the option card and its wiring. If the
option is ordered separately, the customer is responsible for installing the option card and the wiring extensions to the control
compartment.
Danfoss A/S © 2018.10
Default setting Description
STO When not using the optional STO feature, a jumper wire is re-
quired between terminal 10 (or 11) and terminal 19. This set-
up allows the drive to operate with factory default program-
ming values.
Default setting Description
– Common for analog output.
[0] No operation Programmable analog output. 0–20 mA or 4–20 mA at a maxi-
mum of 500 Ω.
+10 V DC 10 V DC analog supply voltage for potentiometer or thermis-
tor. 15 mA maximum.
Reference Analog input. For voltage (V) or current (mA).
Feedback
– Common for analog input.
Default setting
[0] No operation
[0] No operation
N O T I C E
Electrical Installation
Description
Form C relay outputs. For AC or DC voltage.
