Operating Guide | VLT® AQUA Drive FC 202

10.9.4 E5h Enclosed Drive Dimensions

55
(2.2)
1
2000
(78.7)
100
6
(3.9)
600 (23.6) /
800 (31.5)
1 Passive harmonic filter/line reactor cabinet
3 E5h drive cabinet
5 dU/dt cabinet
Illustration 74: Dimensions for E5h Enclosure with Standard Pedestal
188 | Danfoss A/S © 2018.10
2
600 (23.6)
600 (23.6)
3
5
400
(15.8)
2 Options cabinet
4 Sine-wave cabinet
6 Standard pedestal
Specifications
4
1200 (82.7)
AQ262141056213en-000101 / 130R0882
