Operating Guide | VLT® AQUA Drive FC 202
1
2
1 Cabinet screen (lower)
3 DC terminals
Illustration 50:
Connection Points for Mains to Input Power Option (Enclosed Drive Configured without Power Options Cabinet)
Danfoss A/S © 2018.10
2 Input power terminals (contactor option is shown)
4 Grounding bar
AQ262141056213en-000101 / 130R0882 | 83
Electrical Installation
3
4
