Danfoss VLT AQUA Drive FC 202 Operating Manual page 22

Operating Guide | VLT® AQUA Drive FC 202
Table 8: Extra Cabinet Option Codes
Character position
19
Table 9: Cable Infeed Option Codes
Character position
20
Table 10: Auxiliary Power Supply Codes
Character position
21
Table 11: Back-channel Cooling Option Codes
Character position
22
22 | Danfoss A/S © 2018.10
Option code
X
4
6
A
B
Option code
X
T
L
M
Option code
X
1
2
4
5
6
7
8
9
Option code
X
1
C
D
N
Description
None
400 mm (15.8 in), left-hand side
600 mm (23.6 in), left-hand side
400 mm (15.8 in), right-hand side
600 mm (23.6 in), right-hand side
Description
Bottom
Top
Mains top, motor bottom
Mains bottom, motor top
Description
No supply
230 V AC external
230 V AC internal
230 V AC internal + 24 V DC internal
230 V AC external + 24 V DC internal
120 V AC external
120 V AC internal
120 V AC internal + 24 V DC internal
120 V AC external + 24 V DC internal
Description
Bottom in, top out
Back in, back out
Back in, top out
Bottom in, back out
None
Product Overview
AQ262141056213en-000101 / 130R0882
