Operating Guide | VLT® AQUA Drive FC 202
1 Motor cables (U/V/W) to motor terminals (U/V/W) in output
filter cabinet
3 Cabinet heater supply harness to output filter cabinet
5 Thermal protection wiring harness to output filter cabinet
Illustration 32:
Split Shipment Electrical Connections (Input Filter Cabinet + Input Power Options Cabinet + E5h Drive Cabinet)
58 | Danfoss A/S © 2018.10
1
R
S
2
3
4
5
-XD11.1
-XDL.1
T
-XD4.1
2 DC-link harness to fan supply in output filter cabinet
4 Additional terminal connections
Electrical Installation
AQ262141056213en-000101 / 130R0882
