Operating Guide | VLT® AQUA Drive FC 202
Wiring Configuration Examples

8.1.14 Wiring Configuration for a Fixed Variable Speed Pump

L1/L2/L3
L1/L2/L3
L1/L2/L3
Drive
Illustration 66:
Fixed Variable Speed Pump Wiring Diagram
Danfoss A/S © 2018.10
AQ262141056213en-000101 / 130R0882 | 127
