Operating Guide | VLT® AQUA Drive FC 202
• 100 mm (3.9 in)
• 200 mm (7.9 in)
• 400 mm (15.8 in)

10.9.2 D9h Enclosed Drive Dimension

55 (2.2)
1
2000
(78.7)
4
100 (3.9)
400 (15.8)
1 Passive harmonic filter/line reactor cabinet
3 Sine-wave cabinet
Illustration 72: Dimensions for D9h Enclosure with Standard Pedestal
186 | Danfoss A/S © 2018.10
2
400 (15.8)
2 D9h drive cabinet
4 Standard pedestal
Specifications
3
600 (23.6)
AQ262141056213en-000101 / 130R0882
