Operating Guide | VLT® AQUA Drive FC 202
• The 10 most recent changes.
• Changes made from default setting.
Q6 Loggings
Use Q6 Loggings for fault finding. To get information about the display line readout, select Loggings. The information is shown as
graphs. Only parameters selected in parameter 0-20 Display Line 1.1 Small through parameter 0-24 Display Line 3 Large can be viewed. It
is possible to store up to 120 samples in the memory for later reference.
Table 20: Logging Parameter Examples
Q6 Loggings
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Q7 Water and Pumps
The parameters found in the Q7 Water and Pumps contain basic data that is necessary for configuring water pump applications.
Main Menu
The Main Menu mode is used to:
• List the parameter groups available to the drive and drive options.
• Change parameter values.
0.0%
Main Menu
O-** Operation / Display
1-** Load and Motor
2-** Brakes
3-** Reference / Ramps
Illustration 11: Main Menu View
30 | Danfoss A/S © 2018.10
0.00 A
1(1)
Product Overview
Reference [Unit]
Analog input 53 [V]
Motor current [A]
Frequency [Hz]
Feedback [Unit]
AQ262141056213en-000101 / 130R0882
