Parameter 1-53 Model Shift Frequency
Parameter 1-56 U/f Characteristic
Parameter 6-15 Terminal 53 High Ref./Feedb. Value
Parameter 14-37 Fieldweakening Speed

11.4 Required Parameter Settings for Drive Options

On performing a factory reset on the drive, all drive parameters revert to their factory default value. Several drive options have
parameter settings that must be configured differently from the factory default values in order for the options to perform properly.
Table 118: Parameter Setting for the Active Filter Option (Typecode Character 7 = A)
Parameter
Parameter 5-02 Terminal 29 Mode
Table 119: Parameter Settings for the Passive Filter Option (Typecode Character 7 = P/H/L/U)
Parameter
Parameter 5-02 Terminal 29 Mode
Parameter 5-10 Terminal 18 Digital Input
Parameter 5-31 Terminal 29 Digital Output
Table 120: Parameter Settings for the dU/dt and Sine-wave Filter Options (Typecode Character 18 = D/S/1/2)
Parameter
Parameter 5-02 Terminal 29 Mode
Parameter 14-52 Fan Control
Table 121: Parameter Settings for the Indicator Light + Reset Button Option (Typecode Character 28–29 = D1/DA/DB/DC/DD/DE)
Parameter
Parameter 5-40 Function Relay [1]
Parameter 5-40 Function Relay [2]
Parameter 5-11 Terminal 19 Digital Input
194 | Danfoss A/S © 2018.10
International default value
16.7
50 Hz
1500 RPM
1400 RPM
Change value to
[1] Output
Change value to
[1] Output
[51] External Interlock
[188] AHF Capacitor Connect
Change value to
[1] Output
[3] On 100%
North American default value
20.0
60 Hz
1800 RPM
1680 RPM
Change value to
[5] Running
[5] Running
[1] Reset
