Operating Guide | VLT® AQUA Drive FC 202
Table 5: Brake Option Codes
Character position
15
Table 6: Mains Option Codes
Character position
16–17
Table 7: Output Filter Option Codes
Character position
18
Danfoss A/S © 2018.10
Option code
X
B
T
U
Option code Description
MX None
M1 Fusible disconnect
M2 Non-fusible disconnect
M3 Circuit breaker (MCCB)
M4 Contactor
M5 AC reactor
M6 Fuses
MA Fusible disconnect + contactor
MB Non-fusible disconnect + contactor
MC AC reactor + fusible disconnect
MD AC reactor + fusible disconnect + contactor
ME AC reactor + non-fusible disconnect
MF AC reactor + circuit breaker (MCCB)
MG AC reactor + contactor
MH AC reactor + non-fusible disconnect + contactor
Option code
X
D
S
C
1
2
Description
No brake IGBT
Brake IGBT
Safe Torque Off
Brake IGBT + Safe Torque Off
Description
None
dU/dt
Sine-wave
Common-mode
Common-mode + dU/dt
Common-mode + sine-wave
AQ262141056213en-000101 / 130R0882 | 21
Product Overview
