Operating Guide | VLT® AQUA Drive FC 202
Example:
1
2
3
4
5
6
1 Cabinet screen (lower)
3 Brake and load share terminals
5 Ground terminals
Illustration 49:
Connection Points for Mains to Drive Module
82 | Danfoss A/S © 2018.10
2 Terminal cover
4 Mains terminals
6 Grounding bar
Electrical Installation
AQ262141056213en-000101 / 130R0882
