Operating Guide | VLT® AQUA Drive FC 202
3.6.2 Control Compartment Door
1
2
3
4
5
1 Local control panel (LCP)
3 Fault indicator light
5 Insulation fault indicator light
7 0–1 Start switch
9 Nameplate
Illustration 8:
Exterior Door of Control Compartment (Shown with All Options)
26 | Danfoss A/S © 2018.10
6
7
8
9
2 Emergency push-button
4 Run indicator light
6 USB slot
8 Reset button
Product Overview
AQ262141056213en-000101 / 130R0882
