Operating Guide | VLT® AQUA Drive FC 202
Drive model Fuse P/N
N250 Mersen NH3GG69V355
N315 Mersen NH3GG69V425
N400 Mersen NH3GG69V500
N450 Mersen NH3GG69V500
N500 Mersen NH4GG69V630
N560 Mersen NH4GG69V800
N630 Mersen NH4GG69V800
N710 ABB OFAA4GG1000
N800 ABB OFAA4GG1000

5.9.3 Recommended Fuse Ratings for UL Installation

The table values are calculated using correction factors for a 40 °C (104 °F) ambient operating condition and using cables with a
minimum insulation rating of 90 °C (194 °F).
UL Approval is valid for maximum input voltage of 600 V. Per UL508A, the short-circuit current rating (SCCR) is as follows:
• Enclosed drives with a fusible disconnect or fusible disconnect and contactor option have 65 kA SCCR at the rated voltage.
• Enclosed drives with single switchgear (mains contactor only or non-fusible disconnect only option) have a 5 kA SCCR, but can
reach 65 kA if the recommended Class fuses are used upstream.
• Enclosed drives with the MCCB option have a 65 kA interrupting rating for 380–480 V, and a 50 kA interrupting rating for525–690 V.
Table 46: Recommended Fuse Ratings for UL Installation, 380–480 V
Drive mod- Fuse P/N
el
N110 Mersen A4J300
N132 Mersen A4J350
N160 Mersen A4J400
N200 Mersen A4J500
N250 Mersen A4J600
N315 Mersen AABY750
N355 Mersen A4BY800
N400 Mersen A4BY1000
N450 Mersen A4BY1000
N500 Mersen A4BY1000
N560 Mersen A4BY1200
Danfoss A/S © 2018.10
Fuse size Rated cur-
rent [A]
3 355
3 425
3 500
3 500
4 630
4 800
4 800
4 1000
4 1000
Maximum Cutoff cur-
current [A] rent [A]
300 4000
350 4600
400 5000
500 8000
600 9000
750 11500
800 12000
1000 15000
1000 15000
1100 18500
1200 19000
Minimum Maximum
SCCR [kA] fuse rating F1
[A]
8.5 355
9.5 425
12 500
12 500
14 630
19 800
19 800
25 1000
25 1000
Peak let thru Maximum
[A] fuse rating F1
[A]
9000 300
10000 350
10400 400
11500 500
12000 600
28000 750
28000 800
35000 1000
35000 1000
42000 1100
42000 1200
AQ262141056213en-000101 / 130R0882 | 93
Electrical Installation
Minimum Type F1
voltage rat-
ing [V]
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
690 gG/gL
Minimum Class F1
voltage rat-
ing [V]
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
500 Class J
