Adjusting the Monitor's Color Balance
Configuring Content Display
© Polycom, Inc.
In most cases, the monitor you connect to your system provides natural color
without any adjustment. Depending on your environment as well as the model of
monitor, however, the video may exhibit one of these problems:
❑
Picture is too dark
❑
Colors appear faded
❑
Picture has too much of one color — for example, the picture may appear
greenish
If you notice any of these, the monitor needs to be adjusted.
To adjust the monitor for natural color:
1. Go to System > Diagnostics > Video.
2. Select the Color Bars icon to display the color bar test screen.
3. Adjust the color using the monitor's controls for color, contrast, and
brightness. Your monitor may also have controls for tint and temperature.
4. When the colors look right on the test screen, press
control to stop the Color Bars test and show video of the room.
5. If the color appears natural, you do not need to make further adjustments.
If the color still needs adjustment, use the monitor's controls to make small
adjustments until the picture appears natural.
You can present content during calls on a TV monitor or a high-resolution display
when you use:
❑
People+Content IP installed on a computer connected with any VSX system
❑
A Visual Concert VSX data collaboration unit with a VSX 6000 or VSX 7000
system
❑
An ImageShare II device with a VSX 8000 system
For information about ordering the Visual Concert VSX unit, ImageShare II device, or
People+Content IP option, please contact your Polycom distributor.
