Polycom VSX Series Administrator's Manual page 169

Status Tools
Diagnostic Tool
Call Status screen
Displays call type, data speed, and
number dialed for the current call.
In ISDN calls, this screen also displays
connection status for each channel.
Selecting a channel call progress
indicator displays its ISDN number.
In VSX 7000 and VSX 8000 calls placed
through the V.35/RS-449/RS-530 network
interface, this screen displays the states
of these signals:
• DTR
• RTS
• CTS
• DSR
• DCD
• RI
Bright indicators show high signals; dim
indicators show low signals.
Call Statistics screen (VSX 6000,
VSX 7000 and VSX 8000)
Displays call speed, audio and video
protocols, annexes, and error count for
the call in progress.
In multipoint calls, the Call Statistics
screen shows most of this information for
all systems in the call.
Call Detail Report screen
Displays the current Call Detail Report
(CDR) and provides access to the
archived CDR.
© Polycom, Inc.
In the system's user interface
On the Diagnostics screen,
select Call Statistics.
For more information about this screen, see
1. On the Diagnostics screen,
select Call Statistics.
2. Select to go to the Call
Statistics screen.
For more information about this screen, see
page 6-3.
Not available.
For more information about this screen, see
page 6-6.
Chapter 7 - Diagnostics and General Troubleshooting
In the VSX Web
Not available.
Call Status on page
Select Diagnostics > Call
Statistics.
Call Statistics on
Select Utilities > Call Detail
Report.
Call Detail Report on
6-4.
7 - 5
