To connect the main monitor to the VSX room system:
For this
system... Do this
VSX 6000 Connect the monitor to the monitor 1 S-video or composite video output.
Note: S-video provides superior video quality, and is strongly
recommended.
VSX 7000
VSX 8000 1. If you are using a television monitor, connect the S-video cable to the
monitor's S-video input and to the system's Monitor 1 Y (white) and C
(yellow) connectors,
or
If you are using a VGA monitor, connect the VGA cable to the
monitor's VGA input and the system's VGA output.
2. Use the audio cable to connect the monitor's audio inputs to the
system's audio outputs.
After you have finished setting up the system, you will need to configure the monitor's
behavior. Refer to Configuring Monitors on page
Chapter 2 - Setting Up Your System Hardware
4-6.
