Administrator's Guide for the VSX Series
Diagnostic Screens
Status Tools
Diagnostic Tool
System Status screen
Displays system status information,
including auto-answer point to point,
remote control battery, time server, Global
Directory, IP network, gatekeeper, and
ISDN BRI lines.
Call Summary screen
Displays calling information, such as time
spent in calls, total number of IP and
ISDN calls, and percentage of time spent
in IP and ISDN calls.
7 - 4
You can view network statistics and perform diagnostic tests from the VSX
system's Diagnostics screens.
To access the Diagnostics screens on the system:
>> Go to System > Diagnostics.
To access the Diagnostics screens from the VSX Web:
1. On a PC, open a web browser.
2. In the browser address line, enter the system's IP address, for example,
http://255.255.255.255, to go to VSX Web.
3. Click System Setup.
4. Enter admin as the user name, and the admin password, if a password has
been established.
5. Click Diagnostics from any page in VSX Web.
The following diagnostic screens and tools are available:
In the system's user interface
On the Diagnostics screen, select
System Status.
1. On the Diagnostics screen,
select System Status.
2. Select
Summary screen.
For more information about this screen, see
page
to go to the Call
6-2.
In the VSX Web
Select Diagnostics > System
Status.
Select Diagnostics > System
Status > Call Summary.
Call Summary on
