Setting
Echo Canceller
Enable Phantom
Power
VSX 8000
Select and enter speaker settings:
4.
Setting
Master Audio
Volume
Midrange Speaker
VSX 6000
VSX 7000
Subwoofer Speaker
VSX 7000
Subwoofer Level
VSX 7000
Bass
Treble
Line Outputs
VSX 6000
VSX 7000
Description
Lets you specify whether to use the system's built-in echo
canceller.
Do not enable this option if you have connected a Polycom
Vortex mixer or you are using the Polycom StereoSurround
feature.
Allows the system to supply power to microphones connected
directly to the balanced audio inputs.
Note: This selection is only available when you set Input Type
to Microphone.
Description
Sets the volume level for audio from the far site.
Specifies whether to use the system's built-in midrange speaker.
You may prefer to turn off the midrange speaker if you connect
the audio output to Monitor 1 or if you connect an external
speaker system.
Specifies whether to use the system's subwoofer.
You may prefer to turn off the subwoofer speaker if you connect
the audio output to Monitor 1. The system will not operate if you
disconnect the subwoofer.
Sets the volume level for the subwoofer without changing the
master audio volume.
Sets the volume level for the lower frequencies without changing
the master audio volume.
Sets the volume level for the higher frequencies without
changing the master audio volume.
Specifies how the audio output behaves. The default selection,
Monitor - Far Site Audio, supplies audio to the Monitor 1 audio
outputs only when the system is receiving audio from the far site.
If you have connected a VCR to record the conference, select
VCR - Far and Near Audio to supply audio from both the far site
and the system's microphone pods to the VCR.
