ADSP-SC58x Register List
Table A-173: ADSP-SC58x USB0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x310C1040 USB0_FIFO[n]
0x310C1040 USB0_FIFOH[n]
0x310C1044 USB0_FIFOB[n]
0x310C1044 USB0_FIFO[n]
0x310C1044 USB0_FIFOH[n]
0x310C1048 USB0_FIFOB[n]
0x310C1048 USB0_FIFO[n]
0x310C1048 USB0_FIFOH[n]
0x310C104C USB0_FIFOB[n]
0x310C104C USB0_FIFO[n]
0x310C104C USB0_FIFOH[n]
0x310C1060 USB0_DEV_CTL
0x310C1062 USB0_TXFIFOSZ
0x310C1063 USB0_RXFIFOSZ
0x310C1064 USB0_TXFIFOADDR
0x310C1066 USB0_RXFIFOADDR
0x310C1078 USB0_EPINFO
0x310C1079 USB0_RAMINFO
0x310C107A USB0_LINKINFO
0x310C107B USB0_VPLEN
0x310C107C USB0_HS_EOF1
0x310C107D USB0_FS_EOF1
0x310C107E USB0_LS_EOF1
0x310C107F USB0_SOFT_RST
0x310C1080 USB0_MP[n]_TXFUN-
CADDR
0x310C1082 USB0_MP[n]_TXHU-
BADDR
0x310C1083 USB0_MP[n]_TXHUB-
PORT
0x310C1084 USB0_MP[n]_RXFUN-
CADDR
A–268
Description
USB0 FIFO Word (32-Bit) Register
USB0 FIFO Half-Word (16-Bit) Register
USB0 FIFO Byte (8-Bit) Register
USB0 FIFO Word (32-Bit) Register
USB0 FIFO Half-Word (16-Bit) Register
USB0 FIFO Byte (8-Bit) Register
USB0 FIFO Word (32-Bit) Register
USB0 FIFO Half-Word (16-Bit) Register
USB0 FIFO Byte (8-Bit) Register
USB0 FIFO Word (32-Bit) Register
USB0 FIFO Half-Word (16-Bit) Register
USB0 Device Control Register
USB0 Transmit FIFO Size Register
USB0 Receive FIFO Size Register
USB0 Transmit FIFO Address Register
USB0 Receive FIFO Address Register
USB0 Endpoint Information Register
USB0 RAM Information Register
USB0 Link Information Register
USB0 VBUS Pulse Length Register
USB0 High-Speed EOF 1 Register
USB0 Full-Speed EOF 1 Register
USB0 Low-Speed EOF 1 Register
USB0 Software Reset Register
USB0 MPn Transmit Function Address Register
USB0 MPn Transmit Hub Address Register
USB0 MPn Transmit Hub Port Register
USB0 MPn Receive Function Address Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x000000CC
0x0000008C
0x0000005C
0x0000003C
0x00000080
0x00000077
0x00000072
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
