A009: The system received a power-off request at runtime from the HMC, or the white button on the
operator panel was used to power down the system at runtime.
A719: Primary power failed; the system switched to battery backup power.
The following values of bytes 68 and 69, or the first half of word 13, indicate an internal error
occurred in the capacity upgrade on demand (CUoD) firmware or hardware that was corrected. No
action is required by the customer or service representative.
C101, C103, C104, C109, C10B, C10C, C10D, C10E, C10F, C110, C112, C113, C114, C115,
C116, C117, C118, C11A, C11F, C120, C121, C122, C123, C124, C125, C126, C127, C128, C129,
C12A, C12B, C12C, C12D, C12E, C12F, C130, C131, C132, C133, C134, C135, C136, C138,
C13B, C13C, C140, C141, C142, C143, C144, C145, C146, C147, C149, C14A, C14B, C14C,
C14D, C14E, C14F, C150, C151, C152, C153, C154, C155, C156, C158, C159
C11B: This value indicates that the CUoD capacity card (location code U0.1-L1-H1) needs to be
initialized or activated. If the customer is entitled to processor activations, go to step 6 in the
"CUoD Capacity Card" on page 641.
If the customer is not entitled to customer activations, do the following:
1.
Power down the system. Wait until OK is in the operator panel indicating that the service
processor is in standby.
2. From the service processor main menu, enter code 88484 to access the hidden menu.
3. Press enter again at "IBM Authorized Use Only" screen.
4. When the CUoD menu appears, the status of "Test and Run" should be Available.
5. Select option 3 to enter an activation code.
6. Enter the null activation code of 34 zeros: 0000000000000000000000000000000000
7. A success return code should be returned and the Test and Run Status will now be Complete.
8. Now exit out back to the service processor main menu. The system is ready to be powered up.
For all other values of bytes 68 and 69, or the first two bytes of word 13, do the following:
1. Check for system firmware updates. Apply if available.
2. Reset the service processor by activating the pinhole reset switch on the operator panel.
3. Call service support.
Error Code B1xx 8FF0
The following error code was moved out of the Common Firmware Error Code table because of the size of
the description column.
Error Code
Description:
B1xx 8FF0
Informational message
For complete information regarding this error code, read through this entire section.
If the managed server is down, go to the service processor error log and find the error log entry containing
B1xx 8FF0. Examine the first two bytes of word 13 of the detailed entry information.
If the managed server is running, do the following:
v Examine the AIX error log entry containing B1xx 8FF0. This is a FIRMWARE_EVENT error with an
identifier of A6D1BD62.
v In the detail data, find the string B1xx 8FF0. (If present, it will be at byte 60 of the detail data.)
458
EserverpSeries 650 Service Guide
Action/ Possible Failing FRU:
No action required. (The data in these informational log entries
may be used by support personnel to gather additional debug
information.)
