Xenus Plus User Guide
Connector Locations
Connector locations for 1-axis models are shown below.
XEL
Connector locations for 2-axis models, are shown below. Note: J12 is on the upper end-panel.
XE2/800-1819
Copley Controls
XPL
XP2
XML
XM2
16-01344 Rev 06
800-1818/800-1887
87
