Xenus Plus User Guide

3.24: Mechanical and Environmental

XEL/XPL/XML
Size
Weight
Driver without Heat Sink
Low profile (–HL) Heat Sink
Standard (–HS) Heat Sink
Ambient Temperature
Storage
Operating
Humidity
Contaminants
Environment
Cover Material
Cooling
XE2/XP2/XM2/800-1818/800-1819/800-1887
Size
Weight
Ambient Temperature
Storage
Operating
Altitude
Humidity
Contaminants
Ingress Protection
Vibration
Shock
Environment
Cooling
Copley Controls
7.92 in (201,2 mm) X 5.51 in (139,9 mm) X 2.31 in (58,7 mm)
3.0 lb (1.36 kg)
Add 1.86 lb (0.84 kg)
Add 3.1 lb (1.40 kg)
-40 to +85°C
0 to +45°C
0% to 95%, non-condensing
Pollution degree 2
IEC60068-2: 2007
Meets UL Spec 94 V-0 Flammability Rating
Heat sink and/or forced air cooling required for continuous power output
XE2/XP2/XM2 (non "-N" models)/800-1819:
- 9.24 in (234,7 mm) X 5.42 in (137,6 mm) X 3.59 in (91,1 mm)
XE2/XP2/XM2 ("-N" models)/800-1818/800-1887:
- 9.24 in (234,7 mm) X 5.57 in (141,6 mm) X 2.31 in (58,7 mm)
XE2/XP2/XM2 (non "-N" models)/800-1819: 4.19 lb (1.90 kg)
XE2/XP2/XM2 ("-N" models)/800-1818/800-1887: 3.13 lb (1.42 kg)
-40 to +85°C
0 to +40°C
≤ 2000 m per IEC 60068-2-13:1983 if an SPD is used to establish an OVC II
environment
≤ 4000 m per IEC 60068-2-13:1983 if a mains isolation transformer is used to establish
an OVC II environment
0% to 95%, non-condensing
Pollution degree 2
IP20
2 g peak, 10~500 Hz (sine), IEC60068-2-6
10 g, 10 ms, half-sine pulse, IEC60068-2-27
IEC60068-2: 2007
XE2/XP2/XM2 (non "-N" models)/800-1819:
- Integrated heatsink and cooling fan provide required cooling
XE2/XP2/XM2 ("-N" models)/800-1818/800-1887:
- Dependent on mounting orientation and ambient airflow
16-01344 Rev 06
