Xenus Plus User Guide

3.16: Resolver Interface

XEL/XPL/XML
Channels
Type
Signals
Resolution
Reference Frequency
Reference Voltage
Reference Max Current
Max RPM
Function
XE2/XP2/XM2
Channels
Type
Signals
Resolution
Reference Frequency
Reference Voltage
Reference Max Current
Max RPM
Function
800-1819 and 800-1887
Contact Copley Controls for details.
Copley Controls
3
Transmit, 1:1 to 2:1 transformation ratio
Ref(+), Ref(-), Sin(+), Sin(-), Cos(+), Cos(-)
14 bits (equivalent to a 4096 line quadrature encoder)
8 kHz
2.8 Vrms, auto-adjustable by drive for proper feedback levels.
100 mA
20,000
Incremental or analog encoder or resolver required for sinusoidal commutation
and position or velocity modes of operation.
6
Transmit, 1:1 to 2:1 transformation ratio
Ref(+), Ref(-), Sin(+), Sin(-), Cos(+), Cos(-) for each axis
14 bits (equivalent to a 4096 line quadrature encoder)
8 kHz
2.8 Vrms, auto-adjustable by drive for proper feedback levels.
100 mA per axis
20,000
Incremental or analog encoder or resolver required for sinusoidal commutation
and position or velocity modes of operation.
16-01344 Rev 06
