Xenus Plus User Guide

3.18: Serial Interface

XEL/XPL/XML
Channels
Type
Signals
Baud Rate
Data Format
Flow Control
Protocol
Function
XE2/XP2/XM2/800-1818/800-1819/800-1887
Channels
Type
Signals
Baud Rate
Data Format
Flow Control
Protocol
Function
Copley Controls
1
RS-232, DTE
Rxd, Txd, Gnd
9,600 to 115,200 (defaults to 9600 on power up or reset)
N, 8, 1
None
Binary or ASCII format
Set up, control and diagnostics status
1
RS-232, DTE
Rxd, Txd, Gnd
9,600 to 115,200 (defaults to 9600 on power up or reset)
N, 8, 1
None
Binary or ASCII format
Set up, control and diagnostics status
