Xenus Plus User Guide
Analog Sin/Cos Encoder Wiring Diagram
Drive
+
sin
+
cos
+
index
In XEL/XPL/XML there are two encoder +5V outputs at 400 mA each, and in the XE2/XP2/XM2/800-1818
there are 4 encoder +5V outputs at 500 mA each.
Copley Controls
10k 
J10-19
121 
J10-18
-
10k 
10k 
J10-21
121 
J10-20
-
10k 
10k 
J10-23
121 
J10-22
-
10k 
5 V
J10-17
@ 400 mA
J10-5
J10-1
J10
SIN (+)
SIN (-)
COS (+)
COS (-)
INX (+)
INX (-)
+ 5 VDC
Gnd
Frame Gnd
16-01344 Rev 06
SIN (+)
Analog
Encoder
SIN (-)
COS (+)
COS (-)
INX (+)
INX (-)
Encoder
Power
Case
Ground
