A: Regen Resistor Sizing And Configuration - Copley Controls Xenus Plus Series User Manual

Xenus Plus User Guide 16-01344 Rev 06
APPENDIX
A: R R S
EGEN ESISTOR IZING AND
C
ONFIGURATION
This chapter describes the steps used to determine if a regen resistor is required and what the
optimal resistor characteristics would be for a given application. For an overview of regeneration
and regen resistors, see Regen Resistor Theory (p. 61). To configure a custom regen resistor, see
the CME User Guide. Additional information about regeneration can be found in this document on
the web-site: http://www.copleycontrols.com/Motion/pdf/Xenus_regen_guide-03-04.pdf
The contents of this chapter include:
A.1: Sizing a Regen Resistor ......................................................................................................................................................... 135
Copley Controls 134
