Optically Isolated Programmable Inputs Wiring Diagram, XE2/XP2/XM2/800-1818
Opto-isolators
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
Opto-isolators
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
Copley Controls
J9
[COM1]
J9-6
4.99 K
[IN6]
J9-2
4.99 K
[IN7]
J9-3
4.99 K
[IN8]
J9-4
4.99 K
[IN9]
J9-5
J9
[COM2]
J9-17
4.99 K
[IN16]
J9-7
4.99 K
[IN17]
J9-8
4.99 K
[IN18]
J9-9
4.99 K
[IN19]
J9-18
GND
24V
+
+
24V
GND
24V
+
+
24V
