Xenus Plus User Guide
XML
Model Number Description
XML-230-18 Xenus Plus MACRO Servo drive 6/18 A
XML-230-18-HL Xenus Plus MACRO Servo drive 6/18 A with factory-fitted, low-profile heatsink
XML-230-18-HS Xenus Plus MACRO Servo drive 6/18 A with factory-fitted, standard heatsink
XML-230-36 Xenus Plus MACRO Servo drive 12/36 A
XML-230-36-HL Xenus Plus MACRO Servo drive 12/36 A with factory-fitted, low-profile heatsink
XML-230-36-HS Xenus Plus MACRO Servo drive 12/36 A with factory-fitted, standard heatsink
XML-230-40 Xenus Plus MACRO Servo drive 20/40 A
XML-230-40-HL Xenus Plus MACRO Servo drive 20/40 A with factory-fitted, low-profile heatsink
XML-230-40-HS Xenus Plus MACRO Servo drive 20/40 A with factory-fitted, standard heatsink
XML-230-18-R Xenus Plus MACRO Servo drive 6/18 A with resolver feedback
Xenus Plus MACRO Servo drive 6/18 A with resolver feedback and
XML-230-18-R-HL
factory-fitted, low-profile heatsink
Xenus Plus MACRO Servo drive 6/18 A with resolver feedback and
XML-230-18-R-HS
factory-fitted, standard heatsink
XML-230-36-R Xenus Plus MACRO Servo drive 12/36 A with resolver feedback
Xenus Plus MACRO Servo drive 12/36 A with resolver feedback and
XML-230-36-R-HL
factory-fitted, low-profile heatsink
Xenus Plus MACRO Servo drive 12/36 A with resolver feedback and
XML-230-36-R-HS
factory-fitted, standard heatsink
XML-230-40-R Xenus Plus MACRO Servo drive 20/40 A with resolver feedback
Xenus Plus MACRO Servo drive 20/40 A with resolver feedback and
XML-230-40-R-HL
factory-fitted, low-profile heatsink
Xenus Plus MACRO Servo drive 20/40 A with resolver feedback and
XML-230-40-R-HS
factory-fitted, standard heatsink
NOTE: Heatsink kits for field installation may be ordered separately.
XM2
Model
Description
Number
XM2-230-20 Xenus Plus 2-Axis MACRO Servo drive 10/20 A, encoder feedback
XM2-230-20-R Xenus Plus 2-Axis MACRO Servo drive 10/20 A, resolver feedback
XM2-230-20-N Xenus Plus 2-Axis MACRO Servo drive 10/20 A, enc fdbk, no heatsink, fan or internal regen res
XM2-230-20-R-N Xenus Plus 2-Axis MACRO Servo drive 10/20 A, res fdbk, no heatsink, fan or internal regen res
