4.1: General Wiring Instructions

4.1.1: Electrical Codes and Warnings
Be sure that all wiring complies with the National Electrical Code (NEC) or its national equivalent,
and all prevailing local codes.
DANGER: Hazardous voltages.
!
Exercise caution when installing and adjusting.
DANGER
Failure to heed this warning can cause equipment damage, injury, or death.
Risk of electric shock.
High-voltage circuits connected to mains power.
!
XEL/XPL/XML
DANGER
XE2/XP2/XM2/800-1818/800-1819/800-1887
Failure to heed this warning can cause equipment damage, injury, or death.
Refer to the Xenus Plus Dual-Axis STO User Manual
!
The information provided in the Xenus Plus Dual-Axis STO User Manual must be considered
DANGER
for any application using the XE2/XP2/XM2/800-1818/800-1819/800-1887 drive STO feature.
Failure to heed this warning can cause equipment damage, injury, or death.
Do not plug or unplug connectors with power applied.
!
The connecting or disconnecting of cables while the drive has 24Vdc and/or mains power
WARNING
applied is not recommended.
Failure to heed this warning may cause equipment damage.
Do not ground mains-connected circuits.
!
Do not ground Mains connected circuits: J1, J2, J3 and J4 for XE2/XP2/XM2/800-1818/800-
1819/800-1887; J1, J2 and J3 for XEL/XPL/XML.
WARNING
Failure to heed this warning can cause equipment damage.
Risk of Radio Frequency Interference
!
The Xenus Plus Dual Axis drives are not intended for use on a low-voltage public network
which supplies domestic premises.
WARNING
Radio frequency interference should be expected if used on such a network
EMI Line Filter is necessary to meet EMC requirements
!
Use if an EMI Line Filter with Xenus Plus Dual Axis drives is mandatory for meeting EMC
WARNING
requirements
A surge protection device (SPD) or isolation transformer is required to establish an
!
over-voltage category II environment
The AC mains supplying the XE2/XP2/XM2/800-1818/800-1819/800-1887 drives must be
WARNING
limited to over-voltages of Category II. The relevant standards assume AC mains with over-
voltages per OVC III. An SPD or an isolation transformer is required to limit over-voltages to
OVC II levels. The surge protection requirement is limited to models certified to IEC 61800-5-
1 and UL 61800-5-1. The XEL/XPL/XML models are certified to IEC 61010-1 and UL 61010-1
and do not require surge protection.
Copley Controls
16-01344 Rev 06
J1, J2, J3
J1, J2, J3, and J4
