Copley Controls Xenus Plus Series User Manual page 115

Xenus Plus User Guide
Optically Isolated Programmable Inputs Wiring Diagram
Opto-isolators
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
Opto-isolators
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
4.7 K
5.1V
Copley Controls
J9
[COMM_A]
J9-2
4.99 K
[IN7]
J9-3
4.99 K
[IN8]
J9-4
4.99 K
[IN9]
J9-5
4.99 K
[IN10]
J9-6
J9
[COMM_B]
J9-7
4.99 K
[IN11]
J9-8
4.99 K
[IN12]
J9-9
4.99 K
[IN13]
J9-10
4.99 K
[IN14]
J9-11
GND 24V
+
+
24V
GND 24V
+
+
24V
16-01344 Rev 06
115
