Xenus Plus User Guide
Hall Switch Wiring Diagram
Drive
Typical Circuit
10 K
100 pƒ
@ 400 mA
In XEL/XPL/XML there are two encoder +5V outputs at 400 mA each, and in the XE2/XP2/XM2/800-1818
there are 4 encoder +5V outputs at 500 mA each.
Copley Controls
J10
+ 5 Vdc
10 K
U
J10-2
V
J10-3
W
J10-4
5 Vdc
5 V
J10-6
Gnd
J10-5
Frame Gnd
J10-1
16-01344 Rev 06
Halls
Hall
Hall
Hall
Halls
Power
Case
Ground
