3.10: Analog Output

XEL/XPL/XML
Channels 1
Type Single-ended
Range 0-5 Vdc
Resolution 12 Bit
NOTE: There are no analog outputs available on XE2/XP2/XM2/800-1818/800-1819 drives.

3.11: Digital Outputs

XEL/XPL/XML
Channels 6 (OUT1~OUT6)
OUT1~OUT 2
Type Current-sinking, open drain MOSFET with
External flyback diode required if driving
inductive loads
Maximum +40 Vdc
Voltage
Maximum
1 Adc
Sink Current
< 0.2 
Low Level
Output
Resistance
Function Programmable
XE2/XP2/XM2/800-1818/800-1819/800-1887
XE2/XP2/XM2/800-1818: 7 (OUT1~OUT7), 800-1819/800-1887: 5 (OUT1~OUT3,
Channels
OUT6~OUT7)
OUT1~OUT 5
Opto-isolated MOSFET SSR with 1 series
Type
resistor and 36V Zener flyback diodes across
outputs
Maximum
30Vdc
Voltage
Maximum Sink
300 mA
Current
Low Level
Output
Not applicable
Resistance
Programmable
Function
Note: 800-1819 and 800-1887 do not utilize
OUT4~5
Copley Controls
OUT3 OUT4~OUT5
High-speed Opto-isolated
5Vdc CMOS Darlingtons
buffer with 36V
Zener diodes
across
outputs
5Vdc 30Vdc
±32 mA 20 mA
Not Not applicable
applicable (Rout only
(Rout only applies to
applies to MOSFET
MOSFET outputs)
outputs)
OUT 6~OUT 7
Opto-isolated, current-sinking with flyback
diode to +24 Vdc
+32 Vdc
1 Adc
0.14 
Brake/Programmable
16-01344 Rev 06
OUT6
Opto-isolated motor
brake control,
current-sinking with
flyback diode to
+24V
+32 Vdc
1 Adc
0.14 
Brake/Programmable
