Xenus Plus User Guide
D.1.3: XTL-FA-01 Edge Filter Specifications
Input
Output
Peak Current/Peak Current Time
Rise/Fall Time
Differential Mode Inductance
Common Mode Inductance
Nominal Resistance
Agency Approvals
Weight
D.1.4: Thermal Considerations
Cooling Requirements
When used with XE2/XP2/XM2-230-20/800-1818/800-1819/800-1887, XEL/XML/XPL-230-18 or
XEL/XML/XPL-230-36 drives, the XTL-FA-01 operates below maximum temperature values, and
thus requires no cooling fan.
When used with XEL/XML/XPL-40 drives running continuous currents greater than 12 Adc,
the XTL-FA-01 should be cooled with an external fan. The fan should have a flow rate of at least
110 CFM. The filter has been tested using the Comair Rotron MD24B2 24 Vdc powered fan.
Fan Mounting Guidelines
Most of the filter's heat is transferred to ambient air, rather than through the heat plate. Thus, it is
very important to mount the filter and fan in such a way that the fan can blow up through the filter's
cover slots. Mount the filter on edge and mount the fan below it so that it blows up through the cover
slots.
There is no heatsink option for the XTL-FA-01 edge filter.
Copley Controls
Voltage, maximum
Current, maximum
Voltage, maximum
Current, maximum
373 Vdc
20 Adc
373 Vdc
20 Adc
40 Adc for 1 second
500 ns (typical)
82 µH per phase, 162 uH phase-phase (nominal)
220 µH (nominal)
27 milliohms per leg, 54 milliohms phase-phase (nominal)
UL508C, EN60204, RoHS
1 lb. 11 oz.
16-01344 Rev 06
152
