Xenus Plus User Guide

F.4: External Regen Resistor Assemblies

Model Description
XTL-RA-03 Regen Resistor Assembly (for use with XEL/XML/XPL-230-18)
Regen Resistor Assembly (for use with XEL/XML/XPL-230-36, XEL/XML/XPL-230-40
XTL-RA-04
and XE2/XP2/XM2-230-20/800-1818/800-1819/800-1887)
For more
http://www.copleycontrols.com/Motion/Downloads/xenusPlusData.html

F.5: Edge Filter

Model Description
XTL-FA-01 Xenus Plus Edge Filter
XTL-FA-01 Edge Filter Connector Kit (for all Xenus Plus models)
Model Qty
1
XTL-FK 1
2
Note 1: For RoHS compliance, append "/RN01-0000" to the Wago part numbers listed above

F.6: Order Example

Order 1 XEL-230-18 drive with standard heatsink fitted at the factory, Connector Kit, and serial cable
Qty Item
kit:
1 XEL-230-18-HS
1 XEL-CK
1 SER-CK
Copley Controls
information, see
Ref Description
J1 Plug, 5 position, 5.0 mm, female
J2 Plug, 4 position, 5.0 mm, female
-- Insertion / Extraction Tool
Description
Xenus Plus EtherCAT Servo drive with standard heatsink installed
Connector Kit with solder cup connectors
Serial Cable Kit for connecting the PC to the drive
Regen Resistor
Mfr. Model No.
Wago: 721-104/026-047
Wago: 721-105/026-047
Wago 231-131
16-01344 Rev 06
data sheet:
165
