Tandberg Data Magnum 224 Product Manual page 9

1 1 1 1
Figure 1-1
Figure 1-2
Figure 1-3
Figure 1-4
2 2 2 2
Figure 2-1
Figure 2-2
Figure 2-3
Figure 2-4
Figure 2-5
Figure 2-6
Figure 2-7
Figure 2-8
Figure 2-9
Figure 2-10
Figure 2-11
Figure 2-12
Figure 2-13
3 3 3 3
Figure 3-1
Figure 3-2
4 4 4 4
Figure 4-1
Figure 4-2
Figure 4-3
Figure 4-4
Figure 4-5
Figure 4-6
Figure 4-7
A 2007
UGUST
Product Overview
Library front panel components . . . . . . . . . . . . . . . . . . . . . . . . . 3
Library back panel components (SCSI configuration) . . . . . . . . . 5
Library back panel components (FC configuration) . . . . . . . . . . . 6
Library internal components. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the Library
Assembling the left-side rail . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Assembling the right-side rail . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Attaching the left-side rail to the rack . . . . . . . . . . . . . . . . . . . . 15
Placing the library on the rails . . . . . . . . . . . . . . . . . . . . . . . . . 16
Attaching the library to the rails at the back of the rack. . . . . . . 17
SCSI connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fibre Channel connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Ethernet port (SCSI library shown) . . . . . . . . . . . . . . . . . . . . . . 21
USB port (Fibre Channel library shown) . . . . . . . . . . . . . . . . . . 21
Shipping locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Power switch and power connector . . . . . . . . . . . . . . . . . . . . . 22
Shipping lock replacement preparation . . . . . . . . . . . . . . . . . . 24
Shipping lock removal-step 1. . . . . . . . . . . . . . . . . . . . . . . . . . 24
Configuring the Library
Library LCD and keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Library menu organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using the Remote Management Utility
Remote Management Utility-Home page. . . . . . . . . . . . . . . . . 82
Remote Management Utility-Library and Tape Drive Status . . . 85
Remote Management Utility-Status window . . . . . . . . . . . . . . 86
Remote Management Utility-Inventory page . . . . . . . . . . . . . . 89
Remote Management Utility-Configuration home page . . . . . . 91
Remote Management Utility-Statistics home page . . . . . . . . . 100
Remote Management Utility-Tools home page. . . . . . . . . . . . 103
M 224, S
AGNUM
L T24, S
TORAGE IBRARY OR TORAGE
Figures
L 2U
OADER
ix
