Tandberg Data REPLACE TAPE DRIVE IN T24 OR T48 Manual

Installing a tape drive
Hide thumbs

Advertisement

Quick Links

Download this manual
I
NSTALLING A
This document explains how to install or replace a tape drive in the Tandberg
StorageLibrary T24 or Tandberg StorageLibrary T48. Please read the entire section that
you are using prior to beginning the procedure.
P
I
REPARING FOR
Note:
If your library is installed in a rack, it is not necessary to remove the library from the
rack to complete this procedure. It is also not necessary to disconnect the Ethernet
cable from the back of the library.
Obtain these items—a #2 Phillips screwdriver and a small flat-blade screwdriver.
Ensure that the environment is free of conditions that could cause electrostatic
discharge (ESD)—If possible, use an antistatic mat and a grounded static protection
wristband during installation. If a mat and wristband are not available, touch a known
grounded surface, such as a computer's metal chassis.
Warning
Warnung
Advertencia
