3.16 Main Menu - Data Readouts - Group 16

16-00 Control Word
Range: Function:
0 [0 - 65535 ] View the control word sent from the
*
Adjustable frequency drive via the serial
communication port in hex code.
16-01 Reference [Unit]
Range:
0.000 Reference- [-999999.000 -
FeedbackUnit 999999.000
*
ReferenceFeed-
backUnit]
16-02 Reference %
Range:
0.0 % [-200.0 - 200.0 %]
*
16-03 Status Word
Range: Function:
0 [0 - 65535 ] View the status word sent from the Adjustable
*
frequency drive via the serial communication
port in hex code.
16-05 Main Actual Value [%]
Range: Function:
0.00 % [-100.00 - 100.00 View the two-byte word sent with
*
%] the status word to the bus master
reporting the main actual value.
16-09 Custom Readout
Range:
0.00 CustomRea- [-999999.99 -
doutUnit 999999.99
*
CustomRea-
doutUnit]
®
VLT HVAC Drive Programming Guide
Function:
View the present
reference value applied
on impulse or analog
basis in the unit
resulting from the
configuration selected
in 1-00 Configuration
Mode (Hz, Nm or RPM).
Function:
Function:
View the user-defined
readouts as defined in
0-30 Custom Readout Unit,
0-31 Custom Readout Min
Value and 0-32 Custom
Readout Max Value.
MG11CD22 - VLT ® is a registered Danfoss trademark
3.16.1 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0.00 [0.00 - Displays motor power in kW. The value
kW 10000.00 shown is calculated on the basis of the
*
kW] actual motor voltage and motor current.
The value is filtered, and therefore approx.
30ms may pass from when an input value
changes to when the data readout values
change. The resolution of readout value
on serial communication bus is in 10 W
steps.
16-11 Power [hp]
Range: Function:
0.00 [0.00 - View the motor power in HP. The value
hp 10000.00 hp] shown is calculated on the basis of the
*
actual motor voltage and motor current.
The value is filtered, and therefore
approximately 30ms may pass from
when an input value changes to when
the data readout values change.
16-12 Motor voltage
Range: Function:
0.0 V [0.0 - 6000.0 V] View the motor voltage, a calculated
*
value used for controlling the motor.
16-13 Frequency
Range: Function:
0.0 Hz [0.0 - 6500.0 Hz] View the motor frequency, without
*
resonance dampening.
16-14 Motor Current
Range: Function:
0.00 A [0.00 - View the motor current measured as a
*
10000.00 A] mean value, IRMS. The value is filtered,
and thus approximately 30ms may pass
from when an input value changes to
when the data readout values change.
16-15 Frequency [%]
Range:
0.00 % [-100.00 - 100.00 %]
*
3 3
