Danfoss VLT AutomationDrive FC 302 Programming Manual page 154

Parameter Descriptions
14-55 Output Filter
Option:
[2] Sine- This parameter sets a minimum allowed limit to the
Wave switching frequency and ensures that the filter is
Filter operated within the safe range of switching
3 3
Fixed frequencies. Operation is possible with all control
principles. For Flux control principle
parameter 14-56 Capacitance Output Filter and
parameter 14-57 Inductance Output Filter have to be
programmed (these parameters have no effect in
VVC
SFAVM, which gives the lowest acoustic noise in the
filter.
NOTICE
Reset the frequency converter after selecting
[2] Sine-Wave Filter Fixed.
Always set parameter 14-55 Output Filter to
[2] Sine-wave fixed when using a sine-wave
filter. Failure to do so can result in
overheating of the frequency converter,
which can result in personal injury and
equipment damage.
14-56 Capacitance Output Filter
Compensation function of the LC filter requires the per phase
equivalent star-connected capacitance of the filter (3 times the
capacity between 2 phases when capacitance is 'Delta'
connection).
Range:
Size related
*
uF]
14-57 Inductance Output Filter
Range:
Size [0.001 -
related 65 mH]
*
152
Function:
plus
and U/f). The modulation pattern is set to
CAUTION
Function:
[0.1 - 6500 Set the capacitance of the output
filter. The value can be found on the
filter label.
NOTICE
This is required for correct
compensation in Flux mode
(parameter 1-01 Motor Control
Principle).
Function:
Set the inductance of the output filter.
The value can be found on the filter
label.
NOTICE
This is required for correct
compensation in Flux mode
(parameter 1-01 Motor Control
Principle).
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
VLT AutomationDrive FC 301/302
14-59 Actual Number of Inverter Units
Range:
Size related
3.15.7 14-7* Compatibility
The parameters in this group are for setting of compati-
bility for VLT 3000, VLT 5000 to FC 300.
14-72 VLT Alarm Word
Option:
[0] 0 - 4294967295 Read out the alarm word corresponding to
14-73 VLT Warning Word
Option:
[0] 0 - 4294967295 Read out the warning word corresponding
14-74 Leg. Ext. Status Word
Range:
0 [0 - 4294967295] Read out the ext. status word
*
3.15.8 14-8* Options
14-80 Option Supplied by External 24VDC
Option:
[0] No
[1] Yes Select [1] Yes if an external 24 V DC supply is used to
*
NOTICE
This parameter is only changing function by performing
a power cycle.
14-88 Option Data Storage
Range:
0 [0 - 65535] This parameter stores information about options
*
14-89 Option Detection
Selects the behaviour of the frequency converter when a change
in the option configuration is detected.
Option:
[0] Protect Option
*
Config.
Function:
[ 1 - 1] Set the actual number of power units.
*
Function:
VLT 5000.
Function:
to VLT 5000.
Function:
corresponding to VLT 5000.
Function:
Select [0] No to use the frequency converter's 24 V DC
supply.
power the option. Inputs/outputs are galvanically
isolated from the frequency converter when operated
from an external supply.
Function:
over a power cycle.
Function:
Freezes the current settings and
prevents unwanted changes when
missing or defective options are
detected.
MG33MJ02
